Cranes & Handling
Overhead cranes and handling equipment built for heavy, continuous duty.
We design and fabricate EOT and gantry cranes alongside a range of material-handling equipment for factories, workshops and heavy-industry environments.
From girder fabrication to end-carriage assembly, each crane is engineered for its duty class and load path, delivering safe, reliable lifting across long service lives.
Cranes and handling systems for every duty class.
Single & Double Girder
EOT Cranes
Single- and double-girder electric overhead travelling cranes are sized for span, capacity and duty, with girders, end carriages, hoist and controls engineered as one matched system up to 100 tonnes.
Yard & Outdoor
Gantry Cranes
Rail-mounted gantry cranes handle heavy lifting in yards and outdoor bays without an overhead runway, built for weather exposure and continuous duty across long travel paths.
Workstation Lifting
Jib Cranes
Wall-mounted and pillar jib cranes give localised, repetitive lifting at the workstation, with smooth slewing and precise spotting that speeds up machine loading and assembly tasks.
Wire Rope & Chain
Hoists
Wire-rope and chain hoists are selected to duty class and lift height, delivering reliable, controllable lifting as standalone units or integrated into crane and monorail systems.
Box & Plate Fabrication
Crane Girders
Welded box and plate girders are cambered, stress-relieved and inspected to carry rated wheel loads with controlled deflection, giving smooth travel and long fatigue life under continuous duty.
Custom Solutions
Handling Equipment
Bespoke material-handling equipment such as lifting beams, tackle and transfer systems is fabricated to application, making one shop a single source for the lifting systems across a plant.
Cranes engineered around the load path.
EOT & Gantry Cranes
We fabricate single- and double-girder electric overhead travelling cranes and gantry cranes, each sized for its span, capacity and duty so the whole machine, girders, end carriages, hoist and controls, is engineered as a matched system.
Box-Girder Fabrication
Welded box and plate girders are cambered, stress-relieved and inspected to carry rated wheel loads with controlled deflection, giving smooth travel and long fatigue life under continuous industrial duty.
Duty-Class Engineering
Each crane is designed to a defined FEM / IS duty class matched to its usage and load spectrum, so a foundry crane in constant heavy service and an occasional maintenance crane are each built to the right structural and mechanical rating.
VFD Motion Control
Variable-frequency drives on long-travel, cross-travel and hoist motions deliver soft starts, precise spotting and reduced sway, protecting both the load and the structure while improving cycle times.
Flexible Operator Control
Cranes ship with pendant, radio remote or cabin control to suit the workflow, with anti-collision, limit switches and overload protection integrated for safe, repeatable handling.
Handling Equipment Range
Beyond overhead cranes we build jib cranes, wire-rope and chain hoists and bespoke material-handling equipment: a single source for the lifting systems across a plant or workshop.
- Lifting Capacity
- 1 – 100 tonnes
- Crane Span
- Up to 35 m
- Lift Height
- Up to 30 m
- Duty Class
- FEM / IS, up to M7
- Configuration
- Single & double girder
- Motion Control
- VFD on all motions
- Operator Control
- Pendant / radio / cabin
- Safety
- Overload & anti-collision
